MP0040N Field assembly plug, Cat.6A, shielded, MPTL tested
Περιγραφή
The LogiLink field termination plug is perfectly suited for 10 Gigabit networks. Installation is done quick and easily without special tools. This high-quality connector ensures high quality, consistent, reliable terminations and meets the current standards. It is the perfect solution for a high-performance link.
SKU προϊόντος: LL-MP0040N
EAN: 4052792062557
Χαρακτηριστικά
- Cat.6A Class EA Modular Plug Terminated Link (MPTL)
- Comply with ISO/IEC11801, TIA568-C.2, TIA568.2-D
- Fully shielded zinc diecast housing, screw type
- Contact pins with phosphor bronze alloy, gold plated
- For solid wire: 22/1 to 26/1 AWG
- For stranded wire: 23/7 to 27/7 AWG
- Suitable for outer dimension of round cable: 5–8.5 mm
- Wiring code: T568A, T568B or PROFINET
- Suitable for PoE, PoE+, PoE++ and HDBaseT
- Suitable for insulated wire with 1.1–1.6 OD
PDF FILE: mp0040n.pdf
