FB1009 FTTH termination box for Din rail mounting, 4 ports
Περιγραφή
The LogiLink fiber optic termination box for DIN rail mounting is a space-saving and secure connection solution designed specifically for professional FTTH installations. Thanks to its modular design, the box is suitable for the installation of up to four SC simplex or LC duplex adapters (FB1009). It combines adapter mounting and fiber optic splicing functions in a single unit. This makes it ideal for electrical and communications cabinets where reliable and secure fiber optic connections are required.
SKU προϊόντος: LL-FB1009
EAN: 4052792085389
Χαρακτηριστικά
- Fiber splicing outlet for 35 mm Din rail
- For 4 SC-Simplex or LC-Duplex coupler without flange
- Capacity: 4 cores for SC, 8 cores for LCD
- ABS plastic housing, unloaded
- Simple 35-mm DIN rail mounting
- Color: white RAL 9003
- Protection rating: IP40, for indoor use only
- Incl. 4 pcs. heat shrink protective tubes
DATASHEET: FB1009.pdf
